Modbus | Serial RS485 data collection.
Customised edge data processing.
Secure monitoring on a cloud or server.

Screen Shot 2024-05-01 at 3.27.56 pm.png

Deploy container programs, python scripts or machine learning inferences where you collect industrial Modbus data and improve on the fluency, running cost & reliability of your industrial intelligence network.

​​

  • Data Collection & Logging: manage multiple protocol devices including Modbus, CAN, Serial RS485 & Bluetooth.

  • Edge Compute: use our libraries or add your own scripts & containers to the Debian edge gateway.

  • Cloud & Server Connectivity: with integrated AWS, Azure, Ubidots & MQTT clients.

  • Cellular 4G & GPS option: to monitor and track remote or mobile assets.

  • Industrial Certification: robust industrial construction with CE, FCC & RCM certifications.

​

Available as a 'Standard edge Modbus' board or 'LTE + GPS' model.

​

Screen Shot 2023-11-21 at 1.19.00 pm.png
Edge Modbus Gateway nodeG5.png
Image by Joakim Honkasalo

Live Demo

See our Schneider smart power meter demo dashboard.

Select A Model

standard board nodeG5.png
nodeG5 LTE + GPS.png
Specifications
Edge Modbus model
Edge Modbus + LTE/4G model
Processing Core

  • - NXP i.MX8M Plus Quad, quad-core ARM Cortex-A53, 1.8GHZ

  • - NXP AI/ML Neural Processing Unit, up to 2.3 TOPS

  • - Google Coral 4.0 TOPS ML TPU Accelerator (available as an option)

  • - NXP i.MX8M Plus Quad, quad-core ARM Cortex-A53, 1.8GHZ

  • - NXP AI/ML Neural Processing Unit, up to 2.3 TOPS

  • - Google Coral 4.0 TOPS ML TPU Accelerator (available as an option)

Operating System

- Debian 11 OS supporting Docker

- Debian 11 OS supporting Docker

Custom Application Support

  • - Python API library & support

  • - LUA API library & support

  • - TensorFlow application support

  • - Python API library & support

  • - LUA API library & support

  • - TensorFlow application support

RAM

  • - Standard Applications: 2GB RAM

  • - ML Applications: 4GB RAM (available as an option)

  • - Standard Applications: 2GB RAM

  • - ML Applications: 4GB RAM (available as an option)

Storage

- 32GB eMMC

- 32GB eMMC

Data Acquisition & Format

  • - Via Configurable Polling Cycle or REST API (HTTP GET)

  • - Data output format: JSON | XML

  • - Via Configurable Polling Cycle or REST API (HTTP GET)

  • - Data output format: JSON | XML

Data Buffer Type

  • - Collected data is stored in a SQL buffer before sending

  • - Real Time Reporting (no data buffer)

  • - Collected data is stored in a SQL buffer before sending

  • - Real Time Reporting (no data buffer)

Quick Data Functions

  • - Integrated mean value function

  • - Integrated average value function

  • - Integrated mean value function

  • - Integrated average value function

Supported Industrial Protocols

  • - Modbus TCP/RTU

  • - Serial RS485

  • - OPC UA

  • - CAN Bus J1939 & OBD2 (ISO-16765-4)

  • - WiFi & Bluetooth

  • - Modbus TCP/RTU

  • - Serial RS485

  • - OPC UA

  • - CAN Bus J1939 & OBD2 (ISO-16765-4)

  • - WiFi & Bluetooth

I/O & Ports

  • - Up to 2 x RS485 ports

  • - 1 x CAN Bus port

  • - 1 x USB 3.0 TYPE A; 2 x USB 2.0 TYPE A

  • - 1 x HDMI

  • - Up to 2 x RS485 ports

  • - 1 x CAN Bus port

  • - 1 x USB 3.0 TYPE A; 2 x USB 2.0 TYPE A

  • - 1 x HDMI

Integrated Cloud Clients

  • - AWS (IoT Core, Sitewise)

  • - Azure (IoT Hub)

  • - Ubidots

  • - MQTT with TLS Security

  • - AWS (IoT Core, Sitewise)

  • - Azure (IoT Hub)

  • - Ubidots

  • - MQTT with TLS Security

Networking

  • - 2 x 1000Mbps Ethernet LAN Port RJ45 Connectors

  • - 802.11ax WiFi & Bluetooth 5.3 BLE (available as an option)

  • - 2 x 1000Mbps Ethernet LAN Port RJ45 Connectors

  • - 4G/LTE CAT4 Quectel EC25 cellular module (in Global or US bands)

  • - 802.11ax WiFi & Bluetooth 5.3 BLE (available as an option)

GNSS

-

- GPS

Mechanical Specifications

  • - Dimensions:132mm (L) x 84mm (B) x 25mm (H)

  • - Enclosure type: Aluminium

  • - Weight: 550grams

  • - Power Supply: 8 to 36 VDC

  • - Dimensions:132mm (L) x 84mm (B) x 25mm (H)

  • - Enclosure type: Aluminium

  • - Weight: 550grams

  • - Power Supply: 8 to 36 VDC

Operating Temperatures

- Standard: 0 to 60 degree celsius

- Optional: -40 to 80 degree celsius

- Standard: 0 to 60 degree celsius

- Optional: -40 to 80 degree celsius

Mounting Options

  • - Mounting Plate

  • - DIN Rail

  • - Mounting Plate

  • - DIN Rail

Manufacturer Warranty

- 5 years

- 5 years
